●Magnetically coupled, space-saving cylinder permits a wide range of applications
| Field descripiton | Field value | Value descripiton |
|---|---|---|
| With Switch Rail | D | With Switch Rail |
| Bore Size | 25 | Bore Size 25 mm |
| Port Thread Type | – | M Thread,Rc |
| Magnetic Holding Force | H | Holding Force Type H |
| Cylinder Stroke | 25 | 25 |
| Adjustment Type | – | With Adjusting Bolt |
| Auto Switch | – | Without Auto Switch |
| Number Of Auto Switches | – | 2 pcs. Or None |
| Made To Order | – | Standard |
Other specifications
| Field descripiton | Value descripiton |
|---|---|
| Port size (Pneumatic port) | 1/8 |
| Fluid | Air |
| Type | Pneumatic |
| Bulit-in magnet for auto switch | Built-in Magnet |
| Action | Double Acting |
| Cushion | Rubber Bumper |
| Minimum operating pressure [MPa] | 0.18 MPa |
| Maximum operating pressure [MPa] | 0.7 MPa |
| Proof pressure [MPa] | 1.05 MPa |
| Minimum fluid temperature [°C] | -10 ℃ |
| Maximum fluid temperature [°C] | 60 ℃ |
| Minimum ambient temperature [°C] | -10 ℃ |
| Maximum ambient temperature [°C] | 60 ℃ |
| Lubrication | Not required (Non-lube) |
| Minimum piston speed [mm/s] | 50 mm/s |
| Maximum piston speed [mm/s] | 500 mm/s |
| Minimum stroke length tolerance [mm] | 0 mm |
| Maximum stroke length tolerance [mm] | 1.0 mm |
| Cover Material | Aluminum Alloy |
| Material (Cylinder tube) | Stainless Steel |
| Material (Piston) | Aluminum Alloy |
| Material (Piston seal) | NBR |
| Holding Force | 363 N |
