Xy lanh khí 20-CDUK16-30D

●Space-saving cylinder enables cylinders to mount directly on multiple sides
●With auto switch (Series CDU: CDU, CDUW, CDUK, CDUKW, CDU-A,ZCDUK)

Field descripiton	Field value	Value descripiton
With Auto Switch(Built-in Magnet)	D	With Auto Switch
Bore Size	16	Bore Size 16 mm
Port Thread Type	–	M5X0.8 Rc1/8
Cylinder Stroke	30	Standard Stroke 30 mm
Auto Switch	–	Without Auto Switch
Number Of Auto Switches	–	2 pcs. Or None
Made To Order	–	Standard

Other specifications

…

Field descripiton	Value descripiton
Port Size	M5X0.8
Fluid	Air
Type	Pneumatic
Action	Double Acting,Single Rod
Mounting bracket	Basic Style
Cushion	Rubber Bumper
Piston rod end type	Rod End Male Thread
Rod-end Thread Type	M
Rod-end Male Thread Size	M5X0.8
Minimum operating pressure [MPa]	0.10 MPa
Maximum operating pressure [MPa]	0.7 MPa
Proof pressure [MPa]	1.05 MPa
Lubrication	Not required (Non-lube)
Minimum fluid temperature [°C]	-10 °C
Maximum fluid temperature [°C]	60 °C
Minimum ambient temperature [°C]	-10 °C
Maximum ambient temperature [°C]	60 °C
Minimum piston speed [mm/s]	50 mm/s
Maximum piston speed [mm/s]	500 mm/s
Minimum stroke length tolerance [mm]	0 mm
Maximum stroke length tolerance [mm]	+1.0 mm
Non-rotating accuracy [°]	±0.8 °
Proper Tightening Torque	2.45±10％ N·m
Hexagon Socket Head Cap Screw Dia.	M4
Allowable Rotating Torque	0.04 N·m
Piston rod diameter [mm]	6 mm
Piston area IN [mm²]	172 mm²
Piston area OUT [mm²]	201 mm²
Theoretical input [N] (Operating pressure 0.3 MPa)	51.6 N
Theoretical input [N] (Operating pressure 0.5 MPa)	86 N
Theoretical input [N] (Operating pressure 0.7 MPa)	121 N
Theoretical output [N] (Operating pressure 0.3 MPa)	60.3 N
Theoretical output [N] (Operating pressure 0.5 MPa)	101 N
