EC1A series EtherCAT IO modules offer 16/32 digital I/O with fast real-time communication and easy DIN rail mounting for industrial automation.

SKU: 1005008747193293

Category: Remote I/O Module
Tags: automation IO, digital input, digital input output EtherCAT, digital output, DIN rail module, EC1A, EtherCAT, ethercat remote io module, industrial IO module, opto-isolated input, relay output, remote IO

Description

Industrial Digital IO Modules with EtherCAT – EC1A Series

The EC1A series provides high-speed, real-time remote IO solutions for industrial automation applications. Using the EtherCAT protocol, these compact modules support digital input and output with reliable signal acquisition and control.

Key Features

• Dual RJ45 Ethernet ports with 100Mbps EtherCAT support

• Multiple models for digital input (DI), digital output (DO), or mixed IO

• Supports PNP/NPN input types with opto-isolation

• Relay-based output (normally open) with max 220V and 2A per channel

• LED indicators for power, link status, and I/O activity

• 24V DC power input with reverse polarity protection

• IP20-rated plastic enclosure for DIN rail mounting

• Compatible with various EtherCAT master controllers

Applications

Suitable for factory automation, machine control, robotics, smart logistics, environmental monitoring, and educational automation labs. Ideal for systems requiring distributed IO over EtherCAT with minimal wiring complexity.

Technical Specifications

• Protocol: EtherCAT

• Interface: 2×RJ45 ports, CAT6 or higher Ethernet cable

• Speed: 100Mbps, max 100m between nodes

• Digital Input: 24V DC, NPN/PNP, 4mA input current, 16/32 channels

• Digital Output: Relay contact output, 2A per point, 16/32 channels

• Isolation: 500V DC (input and…
