Cảm biến Balluff BAW0031 (BAW R03KC-UAE40B-BP00,3-GS49)

Cảm biến Balluff BAW0031 (BAW R03KC-UAE40B-BP00,3-GS49)
Dimension
30 x 10 x 6 mm
Style Housing
block style
Installation
for flush mounting
Range
1…4 mm
Analog output
Analog, voltage 0…10 V
Output characteristic
falling on approach
Limit frequency –3 dB
1000 Hz
Repeat accuracy per BWN
±35 µm
Non-linearity max.
±150 µm
Housing material
PA 6, GF30
Material sensing surface
PA 6, GF30
Connection
Cable with connector, M8x1-Male, 3-pin, 0.30 m, PUR
Operating voltage Ub
21.6…26.4 VDC
Ambient temperature
0…70 °C
IP rating
IP67
Approval/Conformity
CE
UKCA
cULus
WEEE
